| Specifications |
| Material |
|
Vitreous China |
|
|
|
| Gallons Per Flush |
|
1.6 (0.18 higher than average)
|
vs |
|
|
| Seat Included |
|
Yes |
vs |
28.6% Toilets have Seat Included
|
|
| ADA Compliant |
|
Yes |
vs |
50.5% Toilets have ADA Compliant
|
|
| Trip Lever Placement |
|
Left |
vs |
66.9% Toilets have Left
|
|
| Trapway |
|
2 (0.13 lower than average)
|
vs |
|
|
| Flush Type |
|
Siphon Jet |
vs |
36.5% Toilets have Siphon Jet
|
|
| Comfort Height |
|
Yes |
vs |
52.5% Toilets have Comfort Height
|
|
| Insulated Tank |
|
No |
|
|
|
| Flush Valve Size |
|
3 (0.02 higher than average)
|
vs |
|
|
| Approved for Commercial Use |
|
Yes |
|
|
|
| Lever Placement |
|
Left |
|
|
|
| Flow Rate |
|
1.6 GPF (gallons-per-flush) (0.14 GPF higher than average)
|
vs |
|
|
| Trapway Size |
|
2 " (diameter of the outlet for water/waste exiting (equals average)
|
vs |
|
|
| Water Depth (From Rim) |
|
8-3/4" |
|
|
|
| Application |
|
Residential |
|
|
|
| Glazed Trapway |
|
Yes |
|
|
|
| Tank Trip Lever Placement |
|
Left |
|
|
|
| Dimensions |
| Width |
|
17.25 (0.09 lower than average)
|
vs |
|
|
| Depth |
|
29.25 (0.9 higher than average)
|
vs |
|
|
| Bowl Height |
|
16.75 (0.99 higher than average)
|
vs |
|
|
| Height |
|
33 (5.86 higher than average)
|
vs |
|
|
| Rough In |
|
12" (measured From Wall Behind Toilet To Center Of Waste Outlet Hole In Floor), 12 |
|
|
|
| Overall Height |
|
33" (measured From The Bottom Of The Base To The Highest Point On The Toilet) |
|
|
|
| Overall length |
|
29-1/4" (measured From The Back Of The Tank To The Front Of The Rim) |
|
|
|
| Overall Width |
|
17-1/4" (measured From The Furthest Point On The Left To The Furthest On The Right) |
|
|
|
